P650I insulated access platform hire

The Palfinger P650i insulated access platform, offered for hire across Australia by LinCon, represents the forefront of technology for protected, safe access to live overhead powerlines. With a fibre optic control system and specialist desiccants within the boom control for atmospheric humidity, the P650i is the safest at-height live line work platform available.

Model Max. working height Max. outreach Total weight Drive type Overall length Transport dimensions Max. stabiliser width Cage rotation Cage boom rotation Cage size Max. cage load
p650i

65.00m

27.00m

36,650kg

8 x 8

13.90m

2.50m (w) x 4.20m (h)

8.30m

180°

540°

1.80m x 1.00m

500kg
Machine diagram
Max. working height Max. outreach Total weight Overall length Transport dimensions Cage rotation Cage boom rotation Cage size Max. cage load

13.00m

 6.20m

3,000kg

5.60m

2.00m (w) x 2.30m (h)

 360°

 1.40m x 0.70m

250kg
Machine diagram
  • Why choose this model?

    The P650i has a total weight of 36,650kg and an 8 x 8 drive type, ensuring robust performance. It boasts a maximum working height of 65m, a maximum outreach of 27m, and a load capacity of up to 500kg. This platform enables bare-hand maintenance and heavy repair operations on live lines whilst meeting the highest safety standards.

  • Do you have power in the basket?

    Yes, all trucks have 240v power supply in the basket and have an RCD circuit breaker protection for the 240v, with the exception of insulated units which do not have them.

  • Do you have lifting devices?

    Yes, we have lifting arms that are certified to lift 350kg each, this applies for the access equipment platform industrial units from 32m – 103m.  They are individually certified and serial numbered.

  • Do you have hydraulic connections in your basket?

    Yes, we do, which enables people to use tools such as hydraulic intensifiers – for power works.  This applies for the access equipment platform industrial units from 32m – 103m.

  • What are the biggest baskets you have?

    We have expandable baskets on our trucks which can expand from 2m to almost 4m giving you a huge platform to complete works without compromising basket weight capacity.  This applies for the access equipment platform industrial units 32m – 103m (excluding the 37m).

  • Are your platform controls fixed or movable?

    Our controls are movable and can be moved anywhere within the basket – top rail or bottom rails, allowing for greater flexibility when working.  This applies for the access equipment platform industrial units 32m – 103m.

Hire a P650i today

Contact LinCon today to learn more about our P650I insulated access platform hire options and receive an obligation-free quote tailored to your business or project needs. Simply give us a call or complete our online form with your details to get started.
