ABC180 under bridge unit hire

Model	Max. outreach	Max. downwards reach	Total weight	Drive type	Overall length	Transport dimensions	Rotation (ground)	Rotation (below)	Cage size	Max. cage load
ABC180	18.00m	9.10m	33,520kg	8 x 4	12.00m	2.50m (w) x 4.00m (h)	360°	180°	18.00m x 1.10m	550kg

Max. working height	Max. outreach	Total weight	Overall length	Transport dimensions	Cage rotation	Cage boom rotation	Cage size	Max. cage load
13.00m	6.20m	3,000kg	5.60m	2.00m (w) x 2.30m (h)	0°	360°	1.40m x 0.70m	250kg

Why choose this model?
The ABC180 platform features a total weight of 33,520kg and an 8 x 4 drive type, ensuring robust performance and manoeuvrability while its overall length of 12m and transport dimensions of 2.5m x 4m make it suitable for a variety of locations. It boasts a maximum downward reach of 9.1m and an outreach of 18m and can support a cage load of up to 550kg.
Do you have power in the basket?
Yes, all trucks have 240v power supply in the basket and have an RCD circuit breaker protection for the 240v, with the exception of insulated units which do not have them.
Do you have lifting devices?
Yes, we have lifting arms that are certified to lift 350kg each, this applies for the access equipment platform industrial units from 32m – 103m. They are individually certified and serial numbered.
Do you have hydraulic connections in your basket?
Yes, we do, which enables people to use tools such as hydraulic intensifiers – for power works. This applies for the access equipment platform industrial units from 32m – 103m.
What are the biggest baskets you have?
We have expandable baskets on our trucks which can expand from 2m to almost 4m giving you a huge platform to complete works without compromising basket weight capacity. This applies for the access equipment platform industrial units 32m – 103m (excluding the 37m).
Are your platform controls fixed or movable?
Our controls are movable and can be moved anywhere within the basket – top rail or bottom rails, allowing for greater flexibility when working. This applies for the access equipment platform industrial units 32m – 103m.

Hire an ABC180 - (18m) today

Contact LinCon today to learn more about our ABC180 under bridge unit hire options and receive an obligation-free quote tailored to your business or project needs. Simply give us a call or complete our online form with your details to get started.
