ABC60 under bridge unit hire

Model	Max. outreach	Max. downwards reach	Total weight	Drive type	Overall length	Transport dimensions	Rotation (ground)	Rotation (below)	Cage size	Max. cage load
ABC60	6.00m	4.00m	4,900kg	4 x 2	7.70m	2.00m (w) x 3.90m (h)	360°	180°	6.00m x 1.10m	300kg

Max. working height	Max. outreach	Total weight	Overall length	Transport dimensions	Cage rotation	Cage boom rotation	Cage size	Max. cage load
13.00m	6.20m	3,000kg	5.60m	2.00m (w) x 2.30m (h)	0°	360°	1.40m x 0.70m	250kg

Why choose this model?
The ABC60 features a total weight of 4,900kg and a 4 x 2 drive type, making it manoeuvrable and effective for a variety of tasks. With an overall length of 7.70m and transport dimensions of 2.m x 3.9m, it provides excellent accessibility alongside a maximum downward reach of 4m and a maximum outreach of 6m.
Do you have power in the basket?
Yes, all trucks have 240v power supply in the basket and have an RCD circuit breaker protection for the 240v, with the exception of insulated units which do not have them.
Do you have lifting devices?
Yes, we have lifting arms that are certified to lift 350kg each, this applies for the access equipment platform industrial units from 32m – 103m. They are individually certified and serial numbered.
Do you have hydraulic connections in your basket?
Yes, we do, which enables people to use tools such as hydraulic intensifiers – for power works. This applies for the access equipment platform industrial units from 32m – 103m.
What are the biggest baskets you have?
We have expandable baskets on our trucks which can expand from 2m to almost 4m giving you a huge platform to complete works without compromising basket weight capacity. This applies for the access equipment platform industrial units 32m – 103m (excluding the 37m).
Are your platform controls fixed or movable?
Our controls are movable and can be moved anywhere within the basket – top rail or bottom rails, allowing for greater flexibility when working. This applies for the access equipment platform industrial units 32m – 103m.

Hire an ABC60 - (6m) today

Contact LinCon today to learn more about our AB60 under bridge unit hire options and receive an obligation-free quote tailored to your business or project needs. Simply give us a call or complete our online form with your details to get started.
